- 您现在的位置：买卖IC网 > Sheet目录19116 > 0638321100 (Molex Inc)MINI MAC APPLICATOR
Mechanical Feed-Dual Carrier Metal Strip
PARTS LIST
Mini-Mac Applicator 63832-1100
Item
Order No
Engineering No.
Description
Quantity
Perishable Tooling
63832-1170 63832-1170 Tool Kit (All “Y” Items) REF
1
2
3
4
11
12
13
14
16
21
22
23
24
25
29
33
35
45
52
53
72
73
81
63473-0002 63473-0002 Conductor Punch 1 Y
63445-3862 63445-3862 Conductor Anvil 1 Y
63471-0011 63471-0011 Insulation Punch 1 Y
63445-4809 63445-4809 Insulation Anvil 1 Y
63443-0035 63443-0035 Cut-off Plunger Front 1 Y
63466-0201 63466-0201 Cut-off Plunger Rear 1 Y
63443-0036 63443-0036 Plunger Retainer Front 1 Y
63466-0301 63466-0301 Plunger Retainer Rear 1 Y
63443-1401 63443-1401 Cut-off Blade Rear 1 Y
Other Components (REF 21050)
63466-0504 63466-0504 Cut-off Plunger Striker Front 1
63466-0405 63466-0405 Cut-off Plunger Striker Rear 1
63443-0009 63443-0009 Scrap Chute Front 1
63466-0101 63466-0101 Scrap Chute Rear 1
63700-0539 63700-0539 Cut-Off Plunger Spring 2
63600-0110 63600-0110 M4 Washer, 3 mm Thick 1
63443-0023 63443-0023 Lower Tooling Key 1
63443-2127 63443-2127 Spacer Front 1
63443-0061 63443-0061 Wire Stop 1
63443-0062 63443-0062 Collar-8.00 Lg. 1
63890-0995 63890-0995 Collar-4.05 Lg. 1
11-18-4083 60707-8 Feed Guide 1
63443-6130 63443-6130 Rear Cover 1
Frame
63801-3201 63801-3201 Mechanical Feed Applicator Frame Head REF
82
83
63801-3281
63801-4650
63801-3281
63801-4650
Base
Track Assembly
REF
REF
Hardware
91
92
93
94
95
96
97
98
99
N/A N/A M3 by 6 Lg. SHCS 2**
N/A N/A M4 by 6 Lg SHCS 1**
N/A N/A M4 by 12 Lg SHCS 3**
N/A N/A M4 by 20 Lg SHCS 2**
N/A N/A M4 by 60 Lg. SHCS 2**
N/A N/A M5 by 12 Lg. SHCS 1**
N/A N/A M8 by 30 Lg. BHCS 1**
N/A N/A 3mm by 6 Lg. Roll Pin 1**
N/A N/A M4 Flat Washer 2**
** Available from an industrial supply company such as MSC (1-800-645-7270).
Doc No. 63832-1100
Revision: A
Release Date: 12-05-05
Revision Date: 12-05-05
UNCONTROLLED COPY
Page 3 of 5
